| GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSONAL SPACE SOLUTIONS | ||||||
| Dimensions in mm* | Design | |||||
| Series | Element thickness | Element width* (min./max.) | Clear height* (min./max.) | Framed construction | Panel fixing | Element interconnection/design of the vertical profiles |
| AE65 | 68 | 600/1,250 | 2,000/4,500 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| AE85 | 89 | 600/1,250 | 2,000/5,500 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| AE100 | 105 | 600/1,250 | 2,000/18,000 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| Technology: Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56 Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m * Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department. ** Depending on the sound insulation/weight |
||||||
For more info,send inquiry now
Q:What is the price for movable wall?
A:Our movable wall system is customized and the cost is caculated by total meter. Different
types have different prices. So we need you provide to us detailed dimensions like height by width, finish options, parking options to get a quote. We also need your layout drawing if possible.
Q:Is the movable partition wall acoustic(soudproof)?
A:yes, our movable wall system is soundproof. We have different acoustic materials infill to reach different acoustic rating. And we are the only factory who has passed ASTM acoustic test in HongKong and get Acoustic Test. For type 65 series we can reach 45db, for type 80 we can reach 48db, for type 100 we can reach 56 db.
Q: What finish options you have for partition?
A: There are several options. We can supply you bare PDF/Plywood or gypsum board for your own decoration. We can also supply melamine laminate, high pressure laminate, wood veneer, fabric, PU and so on. It depends on your requirement.
Q:Are you a manufacturer or trading company?
A: We are the biggest operable partion manufacturer in Foshan, Guangdong. You are warmly welcome to visit us anytime.
Q:How to install the partition? Will it difficult to be done?
A:It is easy to install our partitions.Our partitions are top supported system without any floor track in need. So top structure will be very important. We have very detailed drawing and videos showing how to install, so your people just need to follow them step by step.
